Deskripsi:

• Frequency Range: UHF 600-900MHz

• Modulation: PLL

• Adjustable Range: 50MHz

• Channel: 2x100

• Frequency Interval: 250KHz

• Frequency Stability: within ±0.005%

• Dynamic Range: 100dB

• Maximum Frequency Deviation: ±45KHz

• Frequency Response: 80Hz-180KHz ±3dB

• S/N: >105dB

• T.H.D: >=0.5%

• Receiver Specification

• Receiver Mode: Double Conversion Superheterodyne

• Intermediate Frequency: First: 110MHz, Second: 10.7MHz

• Wireless Interface:BNC/50WΩ

• Sensitivity: 12dBμV(80dBS/N)

• Sensitivity Adjustable range: 12-32dBμV

• Spur Suppression: <=75dB

• Maximum Output Level: +10dBV

• Transmitter Specification

• Antenna Mode: Backpack transmitter equips with 1/4 wave whip antenna, handheld microphone equips with built-in helical antenna

• Output Power: High: 30mW, Low: 3mW

• Spur Suppression: -60dB

• Power Supply: 2x1.5V AA battery

• Battery Life: less than 10 hours (30mW), less than 15 hours (2mW)
