TECH SPECS
Intel Specification: ATX 12V V2.4
Dimension(DxWxH): 160mm(D) x 150mm(W) x 86mm(H)
AC Input: 100-240Vac
Input Current: 10A
Frequency: 47-63Hz
APFC PF value: > 0.99
80Plus Certification: 80Plus Gold, up to 92%
Operating Temp.: 0-50°C
Fan Size: 135mm
Protection: OPP/ OVP/ OCP/ UVP/ SCP/ NLO/ OTP/ SIP
Safety: cTUVus, TUV, CB, CE, FCC, BSMI
ErP regulation: ErP 2013 Lot 6
MTBF: > 100,000hrs
Output cable Type: Fully Modular │ Flat Cable
Connector Quantity: 20+4Pin x 1 │ 4+4Pin CPU x 2 │ 6+2Pin VGA x 6 │ SATA x 12 │ Molex x 4
P/N: BP-WG750UMAG-9FM
